| Model No. | Bee2 | Bee2H |
| Resolution | 0.3M Pixels, 640 X 480 | 1M Pixels,1280 X 800 |
| Scanner Speed | 1/30 fps | 1/60 fps |
| Field of View | Diagonal 58°, Horizontal 42°,Vertical 36° | Diagonal 57°, Horizontal 45°, Vertical 30° |
| Scan Precision | 2D≥5mil, 1D≥4mil | 2D≥5mil, 1D≥3mil |
| Performance | Code Reading Test DOF | Code Reading Test DOF |
| Code 128 10mil 18bytes paper code 60~310mm | Code 39 4mil paper high density code 60~110mm |
| Code 128 18bytes phone code 70~260mm | Code 39 110mm paper long code 110~240mm |
| QR 10mil 160bytes paper code 30~120mm | QR 1200bytes paper big code 50~140mm |
| DM 15mil 100bytes paper code 30~200mm | Code 39 18bytes phone code 60~350mm |
| QR 18bytes phone code 50~460mm | QR 18bytes phone code 60~580mm |
| Scan Angle | Roll 360°, Pitch ± 55°, Screw ± 55° |
| Symbology | 2D Code: QR Code, Data Matrix, PDF417 etc. |
| 1D Code: UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128, ISBT 128, Code 39, Code93, Code 11, Interleaved 2 of 5, Industrial 2 of 5, Matrix 25, Standard 25, Coda bar, MSI/MSI PLESSEY, GS1Data Bar, etc. |
| OCR(MRZ): OCR-B MRZ ( Machine Readable Zone ) from ID card,passport and driver’s license. |
| LED | Illumination | White |
| Aimer | RED String/Green String (Need Customization) |
| Physical Parameters | Dimension | (L*W*H) 110mm x 60mm x 185mm |
| Weight | 127g |
| Interface | Interface | UART，USB-COM，USB KBW |
| Cable | 2 meter, automatic shift between USB and port |
| Scan Mode | Trigger Mode/Command Mode/Sense Mode |
| Notification | LED，beeper |
| Environmental | Operating Temperature | -30°C – 70°C |
| Storage Temperature | – 40°C – 80°C |
| Humidity | 5% ~ 95%（no-condensing） |
| Ambient Light | Max.100,000 Lux |
| Electrical Parameter | Input Voltage | 5V±0.5V |
| Operating Current | <200mA |
| Standby Current | <1mA |
